Van Mark – Mark I Series Residential Heavy Duty 2'6"
Van Mark Mark I Series light-duty brake in its shortest length, a 2'0" model (M2-S) with a 14" throat, for short aluminum trim pieces up to .027" and 29 gauge steel.
Price on request
- Pickup in New Brunswick, NJ
- Delivery on our lift-gate truck · zones
- SKU MRT-VAN00010984
About this product
The Mark I Series is the brake that introduced Van Mark’s cam-locking system in 1983, and Van Mark sells it today as a light-duty portable brake for siding, window, door and trim work. This listing is the short bench-size model, which Van Mark builds at 2’0″ long (model M2-S).
A two-foot brake earns its place in the trailer for small parts: window sill and head flashings, short returns, corner caps, outlet and light-block trim, and the odd custom piece that does not justify setting up a full-length brake. At 32 lb, it is easy to carry to wherever the work is.
It works like its longer siblings. The cam-lock clamps the coil, two castings hold the sheet, and the traditional hinge auto-measures a 3/4″ hem, the size used for traditional J-channel pockets. The brake bends up to 180 degrees for hemmed edges. The throat is 14″.
Van Mark capacity ratings for the Mark I, based on standard coil and sheet: .027″ aluminum (3003-H14), 29 gauge painted and galvanized steel, 24 oz soft copper, .032″ soft zinc and 29 gauge 304L stainless. That covers residential trim coil; for heavier metal, step up to a Mark II TrimMaster or one of the industrial brakes.
Bend it from our Aluminum Coil and finish the hems with a Malco hand seamer. It is available from our New Brunswick, NJ warehouse; call (732) 561-4275 to check stock, or add it to your quote.
Specifications
| Manufacturer / series | Van Mark Mark I Series (Light Duty) |
|---|---|
| Throat depth | 14" |
| Weight | 32 lb (14.5 kg) |
| Hinge | Traditional, auto-measures a 3/4" hem |
| Aluminum / steel | .027" 3003-H14 / 29 ga painted or galvanized |
| Copper / zinc | 24 oz soft / .032" soft |
| Stand | Sold separately |
| Warranty | Van Mark 1-year limited warranty |
| SKU | MRT-VAN00010984 |
Goes with it
Questions
Is the Mark I a heavy-duty brake?
No. Van Mark lists the Mark I Series as its light-duty brake, rated for .027" aluminum and 29 gauge steel. For heavier metal, look at the Mark II TrimMaster Heavy-Duty or the Mark IV Industrial TrimMaster.
What hem does it make?
The traditional hinge auto-measures a 3/4" hem, sized for traditional J-channel pockets.
