Motorized Hydraulic Recoiler machine MR10

About this product

The StanGroup MR10 is a recoiler: it winds metal strip back onto a coil, the opposite job of a decoiler. Coil processors place a recoiler at the end of a slitting or processing line so the material leaves the line as a coil again rather than as loose lengths. It is a heavy, fixed industrial unit, listed with the decoilers because it handles coil.

StanGroup’s figures are a maximum coil width of 60″, a maximum outside diameter of 51″, an inside diameter range of 17.7″ to 20.5″ and a maximum coil weight of 10,000 lb. The mandrel is turned by a hydraulic motor at up to 20 rpm, powered by a 10 HP, 220 V three-phase main motor; StanGroup lists the hydraulic motor torque as 1450 but does not state the unit. The machine measures about 142″ x 60″ x 80″ and weighs about 8,000 lb, so it needs a solid floor and rigging to set. StanGroup offers a hydraulic loading cart and a tensioner as options.

It fits at the exit of a line built around the Industrial Gang Metal Slitter, whose 55″ width sits inside the MR10’s 60″. At the entry end, a heavy decoiler such as the Hydraulic decoiler with loading cart 10k lbs completes the setup. Steel Coil and Aluminum Coil are the typical materials.

Available from our New Brunswick, NJ warehouse. Call (732) 561-4275 to check stock, or add it to your quote.
